CL26B-K500 CL63-K500/T1/T2TT5称重传感器DACELL

CL63

使用高强度合金刚，与隔膜焊接并完全密封的构造。

拥有高精度的称重传感器，相比容量来说属于小型，高度低，设置简便。

适合用于例如料斗秤，箱罐秤，负荷试验机等对精度有特殊要求的系统上面。



韩国DACELL大拿CLM-T5称重传感器，CLM-T20传感器，UMI-G500

CLM-T5传感器

低截面压缩传感器，高强度合金钢和隔膜密封全焊接结构 料斗, 罐秤称重。防护等级 IP67

  >SPECIFICATIONS
Specifications
Accuracy
CLM CLH
Rated capacity(R.C.) 500kgf, 1tf, 2tf, 5tf, 10tf, 20tf, 50tf, 100tf, 200tf, 300tf, 500tf 500kgf, 1tf, 2tf, 5tf, 10tf, 20tf, 50tf
Rated output(R.O.) 2mV/V±0.1% 2mV/V±0.1%
Nonlinearity 0.05% of R.O.(100tf, 200tf : 0.1%) 0.02% of R.O.
Hysteresis 0.05% of R.O.(100tf, 200tf : 0.1%) 0.02% of R.O.
Repeatability 0.03% of R.O.(100tf, 200tf : 0.05%) 0.02% of R.O.
Zero balance ±2% of R.O. ±2% of R.O.
Temperature effect, on rated output 0.05% of LOAD/10℃ 0.03% of LOAD/10℃
Temperature effect, on zero balance 0.05% of R.O./10℃ 0.03% of R.O./10℃
Temperature range, compensated -10􀅭60℃ -10􀅭60℃
Temperature range, safe -20􀅭80℃ -20􀅭80℃
Terminal resistance input 700±30Ϊ 700Ϊ
Terminal resistance output 700±3Ϊ 700Ϊ
Insulation resistance bridge/case 2000MΪ 2000MΪ
Excitation recommended 10V 10V
Safe overload 150% R.C. 150% R.C.
Cable length ∅7mm 4core, 3m ∅7mm 4core, 3m
>DIMENSIONS TABLE
Capacity
500kgf (4.903kN) 88 30 16 1.5 M6×1 DP10 70 119 5 60 1.8
1tf
