| | 品牌：SENSTECH | | 型号：STCN-1K/2K/5K/10K/20K | | 加工定制：否 | |
| | 制作工艺：集成 | | 输出信号：模拟型 | | 材料：金属 | |
| | 材料物理性质：绝缘体 | | 材料晶体结构：单晶 | | 防护等级：IP66 | |
| | 线性度：0.1 %F.S | | 迟滞：0.5 %F.S | | 重复性：0.1 %F.S | |
| | 灵敏度：1.5mV/V ±1% | | 分辨率：1000R | | | |
韩国SENSTECH 法兰扭矩传感器
STCN-1K/2K/5K
STCN-10K/20K/50K/100K/200K
| SPECIFICATION
| Rated capacity |
1kgf ~ 200kgf-m |
| Rated output |
1.5mV/V ±1% |
| Nonlinearity |
0.1% of R.O |
| Hysteresis |
0.1% of R.O |
| Repeatability |
0.1% of R.O |
| Terminal resistance input |
350±3.5Ω |
| Terminal resistance output |
350±3.5Ω |
| Insulation resistance |
200MΩ |
| Temperature range compensated |
0.3% R.O/10℃ |
| Temperature range safe |
0.2% Load/10℃ |
| Exitation recommeneded |
10V DC |
| Safe overload |
150% R.C |
|
SBS-1K/2K/5K/10K/300K扭矩传感器
韩国SENSTECH
| Rated capacity |
1kgf ~ 300kgf-m |
| Rated output |
1.5mV/V ±1% |
| Nonlinearity |
0.1% of R.O |
| Hysteresis |
0.1% of R.O |
| Repeatability |
0.1% of R.O |
| Terminal resistance input |
350±3.5Ω |
| Terminal resistance output |
350 ±3.5Ω |
| Insulation resistance |
200MΩ |
| Temperature range compensated |
0.3% R.O/10℃ |
| Temperature range safe |
0.2% Load/10℃ |
| Exitation recommeneded |
10V DC |
| Safe overload |
150% R.C |
