日本UNIPULSE尤尼帕斯UNCDW-200N UNCDW-500N力传感器
详细信息
| | 品牌：UNIPULSE | | 加工定制：否 | | 型号：UNCDW | |
| | 制作工艺：集成 | | 输出信号：模拟型 | | 材料：金属 | |
| | 材料物理性质：磁性材料 | | 材料晶体结构：单晶 | | 防护等级：IP67 | |
| | 线性度：0.1 %F.S | | 迟滞：0.2 %F.S | | 重复性：0.2 %F.S | |
| | 灵敏度：2.0±0.2 | | 分辨率：1/2000 | | | |
日本UNIPULSE尤尼帕斯力传感器 UNCDW-200N UNCDW-500N
日本本土生产 假一赔十
Capacity 200 N / 500 N
Construction material: Stainless steel
Ultra-compact compression type loadcell with a diameter of 7 mm and a height of 5 mm
Specifications
| Model |
UNCDW-200N, UNCDW-500N |
|
| Rated capacity |
200, 500 |
N |
| Rated output |
0.5 or more |
mV/V |
| Safe overload |
120 |
%R.C. |
| Maximum safe overload |
150 |
%R.C. |
| Zero balance |
±20 |
%R.O. |
| Non-linearity |
1.0 |
%R.O. |
| Hysteresis |
1.0 |
%R.O. |
| Repeatability |
1.0 |
%R.O. |
| Compensated temperature range |
＋5～＋50 |
℃ |
| Safe temperature range |
－10～＋80 |
℃ |
| Temperature effect on zero |
0.5 |
%R.O./10℃ |
| Temperature effect on span |
0.5 |
%R.O./10℃ |
| Input resistance |
Approx.350 |
Ω |
| Output resistance |
Approx.350 |
Ω |
| Recommended excitation voltage |
2.5 |
V |
| Maximum excitation voltage |
5 |
V |
| Insulation resistance (DC50V) |
1000 or more |
MΩ |
| Cable |
φ1.6 4-conductor color shield cable. Length 0.5m.
End treatment 5-leads. |
|
| Cable color code |
＋EXC：Red
＋SIG：Green
－EXC：White
－SIG:Blue
SHIELD |
|
| Loadcell material |
Stainless steel |
|
| Deflection at rated |
0.01 |
mm |
| Natural frequency |
200N：116
500N：115 |
kHz |
| Weight |
2 |
g |
