HMP110维萨拉VAISALA温湿度探头

Vaisala HUMICAP® Humidity and Temperature Probe HMP110

Technical Data
Performance
RELATIVE HUMIDITY
Measurement range 0 ... 100 %RH
Accuracy (incl. non-linearity, hysteresis and repeatability)
temperature range 0 ... +40 °C
0 ... 90 %RH ±1.5 %RH
90 ... 100 %RH ±2.5 %RH
temperature range -40 ... 0 °C, +40 ... +80 °C
0 ... 90 %RH ±3.0 %RH
90 ... 100 %RH ±4.0 %RH
Factory calibration uncertainty (+20 °C)
0 ... 90 %RH ±1.1 %RH
90 ... 100 %RH ±1.8 %RH
Humidity sensor Vaisala HUMICAP® 180R
Stability ±2 %RH over 2 years
TEMPERATURE
Measurement range -40 ... +80 °C
Accuracy over temperature range
0 ... +40 °C, ±0.2 °C
-40 ... 0 °C, +40 ... +80 °C ±0.4 °C
Temperature sensor Pt1000 RTD Class F0.1 IEC 60751
DEW POINT
Measurement range -40 ... +80 °C
Accuracy (incl. non-linearity, hysteresis and repeatability)
temperature range 0 ... +40 °C
when dew point depression < 15 °C ±1 °C
when dew point depression 15 ... 25 °C ±2 °C
temperature range -40 ... 0 °C, +40 ... +80 °C
when dew point depression < 15 °C - dew point ±2 °C
depression = ambient temperature - dew point
ANALOG OUTPUTS
Accuracy at 20 °C ±0.2 % of FS
Temperature dependence ±0.01 % of FS/°C
