CI-601A CI-605A称重显示仪韩国凯士CAS
详细信息
| | 品牌：韩国CAS | | 型号：CI-601A CI-605A | | 加工定制：否 | |
| | 显示方式：LCD显示 | | 使用环境温度：-35 +70 | | 结构型式：台式 | |
| | 重量：1.32 kg | | 适用范围：工厂 车间 | | | |
| Model Name |
CI-601A |
CI-605A |
| Load cell applied voltage |
DC 5V |
| No. of load cell connection |
10 (350ohm) |
| Load cell input range |
-2.0mV/V ~ 3.0mV/V |
| Input Sensitivity |
0.5uV/D (certification), 0.3uV/D (non-certification) |
| A/D Internal Degradability |
1/520,000 |
| A/D External Degradability |
1/10,000(OIML/NTEP/KS), 1/20,000(Non approval) |
| A/D Conversion Speed |
200 time/sec |
| A/D Conversion Method |
Sigma Delta |
| Display Type |
4.3" TFT Color LCD |
| Key Specification |
10 number keys, 9 function keys |
| Communication |
Basic |
RS-232(COM1, COM2) |
| Option |
RS422, RS485, Analog_out/BCD_out |
| External in/output |
- |
Input 4/Output 6 |
| Power used |
AC |
AC 100~240V, 50/60Hz |
| Temperature used |
-10℃ ~ 40℃ |
| Certification Specification |
OIML, CE |
| Product Dimension (W x D x H/mm) |
192.9 x 190.2 x 98.4 |
| Product Weight (kg) |
1.5 |
