CI-505A CI-507A称重显示仪韩国凯士CAS
详细信息
| | 品牌：韩国CAS | | 型号：CI505A CI-507A | | 加工定制：否 | |
| | 显示方式：LCD显示 | | 使用环境温度：-35 +70 | | 结构型式：台式 | |
| | 重量：1.32 kg | | 适用范围：工厂 车间 | | | |
| Model Name |
CI-501A |
CI-502A |
CI-505A |
CI-507A |
| Load Cell applied voltage |
DC 10V |
| No. of load cell connection (350 ohm) |
8 (4, 6 formula) |
| Zero-point calibration range |
-0.6mV ~ +42.0mV |
| Input Sensitivity |
0.45uV/D |
| A/D Conversion Method |
Sigma Delta |
| A/D Internal Degradability |
1/520,000 |
| A/D External Degradability |
1/10,000 |
| A/D Conversion Speed |
200 times/second |
| Display |
Unit Display |
kg, g, ton |
| Weight Display |
6-digit LED (Font Size : 25mm) |
| Auxiliary Display |
- |
4 |
5 |
| Power used |
AC 100~250V, 50/60Hz |
| Temperature used |
-10℃ ~ 40℃ |
| External Input |
4 |
| External Output |
- |
6 |
| Product Dimension (W x D x H/mm) |
195 x 189 x 98 |
| Product Weight (kg) |
Approximately 1.8kg |
| Communication |
Basic Spec. |
RS-232C, Current loop, Printer port |
| Option |
Analog out(V-out: 0~10V, I-out: 4~20mA),
BCD In/Out, RS-422, RS-485 |
